Moveable gantry crane DELTA 300

Mobile gantry crane DELTA 300

WLL: 250 - 5000 kg
Hp=3000 mm (other heights available by e-mail)

Working Load Limit (t)
Length (mm)
Hoist
£1,125.78
£1,350.94 tax incl.
£1,125.78 tax excl.
Quantity
  Product available. Shipping: 1-2 days

Optional accessories

Accessories

SK directional lock for crane

SK directional lock for crane

£154.00
SA Anti-run cover

SA Anti-run cover

£205.00
SG additional electrical socket at the hoist for crane

SG additional electrical socket at the hoist for crane

£154.00
10 pcs
Lead time: 30-60 days + transport* Lead time: 30-60 days + transport*
100% secure payments

FREE SHIPPING FOR ORDERS OVER £300


The gantry crane is designed for lifting, lowering and moving loads located in its working space, which is determined by the length of the bearing beam.
The load capacity of the gantry winch is determined for the entire range of work of the bearing beam.

There is a possibility to customize the crane to specific customer requirements.
Send inquiry on: sales@craneplex.co.uk



Outreach
 [m]: 		 1  2  3  4  5  6
 WLL
 [kg]:		 250   *  *  *  *  *  *
500   *  *  *  *  *  *
1 000   *  *  *  *  *  *
1 500   *  *  *  *  *  *
2 000   *  *  *  *  *  *
3 000   *  *  *  *  *  *
5 000   *   *  *  *  *  *

There is a possibility to customize the gantry crane to specific customer requirements.

Recommended equipment. Optional:

  • electric chain hoist ESW + trolley EWP
  • electric chain hoist ESW + electric trolley EWE

ESW+EWP ESW+EWE

wciagnik lancuchowy elektryczny VX.jpg
Power supply: 400V three-phase Power supply: 400V three-phase
Code WLL Vlifting Code WLL Vlifting GNP
[kg] [m/min] [kg] [m/min] ISO/FEM
ESW-EWP 00.125-3.0 125 8/2 ESW-EWE 00.125-3.0 125 8/2 M5/2m
ESW-EWP 00.16-3.0 160 8/2 ESW-EWE 00.16-3.0 160 8/2 M5/2m
ESW-EWP 00.25-3.0 250 8/2 ESW-EWE 00.25-3.0 250 8/2 M5/2m
ESW-EWP 00.5-3.0 500 8/2 ESW-EWE 00.5-3.0 500 8/2 M5/2m
ESW-EWP 01.0-3.0 1000 8/2 ESW-EWE 01.0-3.0 1000 8/2 M5/2m
ESW-EWP 01.6-3.0 1600 4/1 ESW-EWE 01.6-3.0 1600 4/1 M5/2m
GNP M5/2m ESW-EWE 02.0-3.0 2000 4/1 M5/2m
ESW-EWE 03.0-3.0 3000 6/1,5 M4/1Am
ESW-EWE 05.0-3.0 5000 3/0,75 M5/2m

Control:

cassette control ST for ESW+EWP

cassette control ST for ESW+EWE


Electric hoist gantry cranes are equipped with:

  • an electric box with a receiving socket
  • single or optional double cable route
  • optional additional electrical socket at the hoist, enabling powering suspended devices, e.g. vacuum grippers with an electric pump

Wheelsets can be optionally equipped with:

• direction lock (every 90 °)
• underrun protection


Chassis - four swivel castors with brakes.

Product Details

DELTA 300
10 Items

grade FREE SHIPPING FOR ORDERS OVER £300 (UK MAINLAND)

THERE IS A HANDLING CHARGE OF £20 FOR ORDERS UP TO £300

(This is for the preparation of the products for shipment and delivery)


loyalty DISCOUNTS FOR THIS PRODUCT

• 5% - purchases over 5000 £

The discount will be automatically applied to your cart. Does not apply to products on sale.


* TRANSPORT

The stated lead time depends on the parameters of the device. The delivery time depends on the size and the time needed to manufacture the device. The exact delivery time is determined after the order has been placed. If the lead time needs to be accelerated, we can offer express delivery after prior agreement on delivery and cooperation. For an extra charge, direct transport from the manufacturer's warehouse to the customer's warehouse or to any other location indicated is possible. This helps speeds up delivery times.
